| ⊙ NEOSEAL® series (B-1, B-3, B-W) |
 |
| -Excel at adhesiveness, waterproof and sustainability. |
| -Fined texture and non-sticky tactile sensation. |
| -No irritating odor because of non-solvent type. |
| -Good at workability under low temperature environment. |
| ITEM |
NEOSEAL B-1 |
NEOSEAL B-3 |
NEOSEAL B-W |
TEST METHOD |
| Appearance |
Gray |
Dark gray |
White |
Observation |
| Hardness |
63 |
64 |
65 |
JIS A 5752 Load:100g*5sec. |
| Specific Gravity |
2.05 |
2.05 |
2.05 |
Convert weight in water |
| Temp. Resistance |
Not Particular |
80℃*72Hr / -20℃*72Hr |
| Flame Resistance |
UL-94 V-0 |
- |
- |
Fire test of the plastic material |
| Size & Package |
each piece @80x40x160mm(=1kg), 20pcs/carton |
| ⊙ PLASEAL® series (B-UF) |
 |
| -Passed non-combustibility standard level at combustion test for materials of train car uses & NFPA 130/EN 45545-2. |
| -Easy operation and superior to frame-resistance. |
| -Fined texture and non-sticky tactile sensation. |
| -No irritating odor because of non-solvent type. |
| ITEM |
PLASEAL B-UF |
TEST METHOD |
| Appearance |
Gray |
Observation |
| Hardness |
64 |
JIS A 5752 Load:100g*5sec. |
| Specific Gravity |
2.0 |
Convert weight in water |
| Temp. Resistance |
Not Particular |
80℃*72Hr /-20℃*72Hr |
| Flame Resistance |
UL-94 V-0 |
Fire test of the plastic material |
| Size & Package |
each piece @80x40x160mm(=1kg), 20pcs/carton |
| ⊙ PLASEAL® series (NF-12HM) |
 |
| -Easily usable with a split. |
| -Highly efficient workability with flexibility even under low |
| temperature. |
| ITEM |
PLASEAL NF-12HM |
TEST METHOD |
| Appearance |
Gray |
Observation |
| Hardness |
70 |
JIS A 5752 Load:100g*5sec. |
| Specific Gravity |
1.6 |
Convert weight in water |
| Size & Package |
each piece @80x40x200mm(=1kg), 20pcs/carton |
| ⊙ PLASEAL® series (S-1) |
 |
| -Most suitable for resin piping under high temp. |
| -No shrinkage, cracking and slumping for 1,000hr at 110℃. |
| -Closely adhered with elasticity even after cured. |
| -Water-tightness at IP44 & flame ressistane of UL94V-0 class. |
| ITEM |
PLASEAL S-1 |
TEST METHOD |
| Appearance |
Base: Blue |
Hardener: Orange |
Observation |
| Gray (after mixed) |
| Specific Gravity |
1.7 |
Convert weight in water |
| Mixing Ratio |
1:1 |
Ratio by weight |
| Usable Time |
8hr |
Originally measured (20ºC/100g) |
| Curing Time |
48hr |
Originally measured (20ºC/100g) |
| Hardness (HDA) |
54 |
JIS K7215 (20ºC/48hr) |
| Flame Resistance |
UL-94 V-0 |
Fire test of the plastic material |
| Package |
75g/pc, 2pcs(150g)/set; 2sets/box, 10box/carton |
| ⊙ KICKNEN® series (B-7V) |
 |
| -Keeping rodents away from applied areas with long-term sustainable repellent effect. |
| -It is flame retardant and has excellent performance in terms of adhesion and sealing properties. |
| ITEM |
KICKNEN B-7V |
TEST METHOD |
| Appearance |
Light Gray |
Observation |
| Hardness |
50 |
JIS A 5752 Load:100g*5sec. |
| Specific Gravity |
2.0 |
Convert weight in water |
| Temp. Resistance |
Not Particular |
80℃*72Hr / -20℃*72Hr |
| Flame Resistance |
UL-94 V-0 |
Fire test of the plastic material |
| Size & Package |
each piece @80x40x160mm(=1kg), 10pcs/carton |
* All data herein is measured originally, it does not guarantee as a standardized data.
| ⊙ APPLICATIONS |
 |
ADHESION
